A Comparison of Film Cooling Techniques in a High Speed, True Scale, Fully Colled Turbine Vane Ring (Paperback) (ISBN-13: 9781249587606)

An effort was undertaken to understand the impact of different film cooling configurations in a true scale turbine vane for three proprietary airfoil designs. The measurements for this study were taken at the United States Air Force Turbine Research Facility (TRF). The TRF enabled heat transfer data to be obtained on full scale turbine hardware under realistic engine conditions. The surface heat flux of the turbine blades was analyzed using the impulse response method. The overall effectiveness was compared between airfoil types at 60% span over varying streamwise locations on both suction and pressure surfaces. Using an approximated massflow, a comparison of the overall effectiveness with respect to massflow rate could be made between airfoils at three different airfoil locations. The shaped hole and slot cooling configurations were found to have higher average overall effectiveness for lower massflow rates than the multiple hole configuration based on the conditions tested.


Author: Michael J. Umholtz
ISBN-10: 1249587603
ISBN-13: 9781249587606
Publisher: Biblioscholar
Language: English
Published: 10/03/2012
Pages: 72
Format: Paperback
Weight: 0.32lbs
Size: 9.69h x 7.44w x 0.15d
