A Sizing Methodology for the Conceptual Design of Blended-Wing-Body Transports (Paperback) (ISBN-13: 9781288909650)

This paper describes the development of a methodology for sizing Blended-Wing-Body (BWB) transports and how the capabilities of the Flight Optimization System (FLOPS) have been expanded using that methodology. In this approach, BWB transports are sized based on the number of passengers in each class that must fit inside the centerbody or pressurized vessel. Weight estimation equations for this centerbody structure were developed using Finite Element Analysis (FEA). This paper shows how the sizing methodology has been incorporated into FLOPS to enable the design and analysis of BWB transports. Previous versions of FLOPS did not have the ability to accurately represent or analyze BWB configurations in any reliable, logical way. The expanded capabilities allow the design and analysis of a 200 to 450-passenger BWB transport or the analysis of a BWB transport for which the geometry is already known. The modifications to FLOPS resulted in differences of less than 4 percent for the ramp weight of a BWB transport in this range when compared to previous studies performed by NASA and Boeing.

Author: National Aeronautics and Space Administr,William M. Kimmel,Kevin R. Bradley
ISBN-10: 1288909659
ISBN-13: 9781288909650
Publisher: Biblioscholar
Language: English
Published: 03/12/2013
Pages: 42
Format: Paperback
Weight: 0.21lbs
Size: 9.69h x 7.44w x 0.09d
