Aerodynamic Loads at Mach Numbers from 0.70 to 2.22 on an Airplane Model Having a Wing and Canard of Triangular Plan Form and Either Single or Twin Ve (Paperback) (ISBN-13: 9781287275244)

Tabulated results of a wind-tunnel investigation of the aerodynamic loads on a canard airplane model with a single vertical tail are presented for Mach numbers from 0.70 to 2.22. The Reynolds number for the measurements was 2.9 x 10(exp 6) based on the wing mean aerodynamic chord. The results include local static pressure coefficients measured on the wing, body, and vertical tail for angles of attack from -4 deg to + 16 deg, angles of sideslip of 0 deg and 5.3 deg, vertical-tail settings of 0 deg and 5 deg, and nominal canard deflections of 0 deg and 10 deg. Also included are section force and moment coefficients obtained from integrations of the local pressures and model-component force and moment coefficients obtained from integrations of the section coefficients. Geometric details of the model and the locations of the pressure orifices are shown. An index to the data contained herein is presented and definitions of nomenclature are given.

Author: Nasa Technical Reports Server (Ntrs)
ISBN-10: 1287275249
ISBN-13: 9781287275244
Publisher: Bibliogov
Language: English
Published: 08/02/2013
Pages: 326
Format: Paperback
Weight: 1.29lbs
Size: 9.69h x 7.44w x 0.68d
