Antenna Coupling Effects in Handheld and Mobile Applications (Paperback) (ISBN-13: 9783639156089)

This work analyzes antenna coupling effects in small wireless handheld and mobile devices. Further it provides suggestions how to minimize them. Modern communication devices have to support several standards, while the total system and PCB size needs to be decreased. This results in rising mutual coupling. Demands for improved receiver sensitivity and limited transmit power aggravate the requirements on separation of the systems. Part 1 presents information about standards, wave propagation on PCBs, fundamentals of 3D electromagnetic FEM simulations and S-parameter measurement basics. Part 2 deals with the results from the simulation of simplified mobile phone boards. Part 3 presents the measurement results of selected configurations. It is shown that the optimization of the antenna positions provides an option to relax demands to the needed filters. In addition modifications to the PCB are introduced which significantly improve decoupling between the antennas.

Author: Mario Rößler
ISBN-10: 3639156080
ISBN-13: 9783639156089
Publisher: VDM Verlag
Language: English
Published: 07/15/2009
Pages: 152
Format: Paperback
Weight: 0.51lbs
Size: 9.00h x 6.00w x 0.35d
