Ares I Scale Model Acoustic Test Instrumentation for Acoustic and Pressure Measurements (Paperback) (ISBN-13: 9781289070892)

Ares I Scale Model Acoustic Test (ASMAT) is a 5% scale model test of the Ares I vehicle, launch pad and support structures conducted at MSFC to verify acoustic and ignition environments and evaluate water suppression systems Test design considerations 5% measurements must be scaled to full scale requiring high frequency measurements Users had different frequencies of interest Acoustics: 200 - 2,000 Hz full scale equals 4,000 - 40,000 Hz model scale Ignition Transient: 0 - 100 Hz full scale equals 0 - 2,000 Hz model scale Environment exposure Weather exposure: heat, humidity, thunderstorms, rain, cold and snow Test environments: Plume impingement heat and pressure, and water deluge impingement Several types of sensors were used to measure the environments Different instrument mounts were used according to the location and exposure to the environment This presentation addresses the observed effects of the selected sensors and mount design on the acoustic and pressure measurements


Author: Nasa Technical Reports Server (Ntrs),Magda B. Vargas,Douglas Counter
ISBN-10: 128907089X
ISBN-13: 9781289070892
Publisher: Bibliogov
Language: English
Published: 06/27/2013
Pages: 30
Format: Paperback
Weight: 0.16lbs
Size: 9.69h x 7.44w x 0.06d
