Cold-Flow Testing of a Subscale Model Exhaust System for a Space-Based Laser (Paperback) (ISBN-13: 9781249449263)

The purpose of this research was to continue a study of gas-dynamic phenomena that occurred in stacked cylindrical rings of nozzles and an exhaust manifold as reported by Captain Scott Bergren in 2002. The rings and exhaust manifold were part of a 1/5- scale model of one quadrant of the conceptual Space Based Laser Integrated Flight Experiment (SBL IFX) gas dynamic laser. This model was mated to a blowdown/ vacuum wind tunnel and consisted of a nozzle array, centerbody, supersonic diffuser, and a transition structure to mate the vacuum and test section. During Capt Bergren's research, supersonic flow was found to only last for 0.2 seconds from wind tunnel startup. The short duration of the supersonic flow was due to the transition structure being too small and not being able to "swallow" the shock wave. The objectives of this research were to remodel the transition structure and evaluate the test section to see if simulation of the expected fluid flow properties in the conceptual SBL IFX design was possible using cold-flow. The transition structure was remodeled to capture the entire vacuum line entrance area while still mating to the diffuser exit. Using rapid data acquisition and schlieren photography, results indicated that supersonic flow lasted for approximately 10 seconds from startup. During this time, a well-defined oblique shock wave inside the optical cavity attached to the leading edge of the centerbody, where the flow reached a velocity of Mach 2.8.

This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work.

This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work.

As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.
