Creo Parametric 5.0: Advanced Assembly Design and Management (Paperback) (ISBN-13: 9781951139568)

Understand the full assembly functionality of the Creo Parametric 5.0 software while concentrating on techniques that maximize large assembly management capabilities as well as an introduction to Top Down Design. Creo Parametric 5.0: Advanced Assembly Design and Management is a hands-on guide with a substantial amount of time dedicated to practices.

This guide was developed against Creo Parametric 5.0.3.0.

Topics Covered

• Advanced Component Selection and Placement
• Top Down Design
• Managing External References
• Assembly Management
• Skeleton and Motion Skeleton Models
• Assembly Duplication Tools
• Assembly Family Tables
• Display Styles, Layers and Suppression
• Restructure
• Intelligent Fasteners Lite
• Creating Parts and Features in an Assembly
• Merge and Cut Out, Intersections
• Copy Geometry Features
• Inheritance Features
• Simplified Representations
• Interchange Assemblies

Prerequisites

• Access to the Creo Parametric 5.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Creo Parametric 5.0: Introduction to Solid Modeling or equivalent Creo Parametric experience.
