Design and development of an embedded system for Micro Stepper Motor (Paperback) (ISBN-13: 9783659216084)

This work explains the Importance of Micro stepper motor in various fields like military, medical applications, process control system, machine tools, manufacture of packaged foodstuffs, robotics, textile industry, integrated circuit fabrication and commercially used. So accurate control of stepper motor is necessary for these applications In general, stepper motors are driving in full step, half step and micro-step modes. In this wok for operating the micro step we used A3977 Driver. The A3977 translator converts the STEP and DIRECTION inputs into the control signals required to sequence the current in each of the two H-bridge outputs for full- half- quarter- and eighth-step micro stepping operation of a bipolar stepper motor. The A3977 is a complete micro stepping motor driver with built in translator for easy operation with minimal control lines. It is designed for operating bipolar stepper motors in full-, half-, quarter-and eighth-step modes.

Author: G. K. Sivasankarayadav,T. Sathya Yadav,P. Thimmaiah
ISBN-10: 3659216089
ISBN-13: 9783659216084
Publisher: LAP Lambert Academic Publishing
Language: English
Published: 08/18/2012
Pages: 108
Format: Paperback
Weight: 0.37lbs
Size: 9.00h x 6.00w x 0.26d
