Design, Modelling and Application of the IGBT (Paperback) (ISBN-13: 9783639185522)

Power semiconductor devices are critical components within power electronics technology. In this thesis, physical operating mechanisms of conventional IGBT structures are analyzed, designed and optimized. Conductivity modulation is studied in detail. A new composite model possessing fast computational speed and reasonable accuracy is proposed. Effects of the two-dimensional IGBT structure on its electrical characteristics are analyzed. A model accounting for these effects is proposed, verified and found to be useful in both device structure design and circuit simulation. In addition, IGBT models in the literature are reviewed, classified, analyzed and compared. IGBT modelling requirements, problems and trends are discussed. The thesis also studied IGBT application problems including off-state negative gate bias requirements and the usage of turn-on snubbers. Electrical/thermal/failure behavioural differences between PT IGBTs and NPT IGBTs are studied.

Author: Kuang Sheng
ISBN-10: 3639185528
ISBN-13: 9783639185522
Publisher: VDM Verlag
Language: English
Published: 10/01/2010
Pages: 196
Format: Paperback
Weight: 0.65lbs
Size: 9.00h x 6.00w x 0.45d
