Digital Pulse Width Modulator (Paperback) (ISBN-13: 9783639178760)

We describe the design of a micropower digital pulsewidth modulator (PWM) for a hearing instrument Class D amplifier. The PWM embodies a novel delta- compensation sampling process and a novel pulse generator.The delta-compensation sampling process is sampled at the same low rate as reported algorithmic sampling processes and it features a similar low total harmonic distortion (THD). Its arithmetic computation is however, substantially simplified. We analytically derive the double Fourier series expression and show that the THD is low.The pulse generator is based on a hybrid 9-b counter 3-b tapped-delay-line. We investigate the compromise between the different design parameters that affect its power dissipation and THD. The complete proposed PWM features a simple circuit implementation, micropower low voltage operation, low sampling rate and low harmonic distortion, thereby rendering it suitable for a practical digital hearing instrument.

Author: Huiyun Li
ISBN-10: 3639178769
ISBN-13: 9783639178760
Publisher: VDM Verlag
Language: English
Published: 07/10/2009
Pages: 96
Format: Paperback
Weight: 0.33lbs
Size: 9.00h x 6.00w x 0.23d
