Experimental Study of the Subsonic Aerodynamics of a Blended Wing Body Air Vehicle With a Focus on Rapid Technology Assessment (Paperback) (ISBN-13: 9781025082684)

The subsonic aerodynamic performance of a blended wing body aircraft constructed using selective laser sintering was assessed in the AFIT low-speed wind tunnel. The scaled-down model of a strike tanker aircraft consisted of a shaped fuselage and sweptback wings. The Reynolds number, based on mean wing chord, during testing was on the order of 105 while the Mach number ranged from 0.10 to 0.20. The model evaluation and analysis process included force and moment measurements acquired from a wind tunnel balance, pressure data measured with 8 taps located on the model's upper surface, a comparison to computational fluid dynamics (CFD) solutions acquired in a parallel study conducted by AFRL/VAAC, and global pressure sensitive paint (PSP) measurements. Paint measurements were compared to pressure tap data to ensure their accuracy while lift and drag coefficients, as well as pitching and rolling moments were examined to determine performance characteristics, including stability attributes and aircraft stall. One of the most interesting results was the striking difference in the force and moment measurements before and after the paint was applied to the surface. The average surface roughness, Ra, was measured with a profilometer and was found to have increased from approximately 0.3 m to 0.7 m when the paint was applied. When traditional 2-D boundary layer approaches to assessing the effect of roughness, the 0.7 m value falls well below the threshold at which one would anticipate roughness to have any effect. There is support in archival literature for the notion that roughness effects are more pronounced in a 3-D boundary layer, and the pitching moment data and the PSP data indicate that the for the painted model, there is a gradual onset of wing stall marching inward from the wingtips toward the body. By contrast, the force and, in particular, the pitching moment data suggests that the onset of wing stall is sudden across the entire wing for the unpainted case.
Inte

This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work.

This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work.

As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.
