Full-Wave Based Validation of Stripline Field Applicator for Low Frequency Material Measurements (Paperback) (ISBN-13: 9781288331888)

This research presents the analysis and veri cation of a stripline designed by Air Force Research Laboratory for use in measuring the electrical properties of materials at low frequencies and high temperature. It is designed to operate in the TEM mode up to 4 Ghz and have a characteristic impedance of 50 ohms. A full wave base method is used to analyze the structure. A pair of coupled electric eld integral equations (CIE) are formulated using The parallel plate waveguide dyadic Green's function. These CIEs are solved through a computationally e cient entire-domain method of moments (MoM) technique. Numerical e ciency are gained through employing Chebsyshev polynomials of the rst and second kind as testing and expansion functions. Further numerical e ciencies are gained by taking advantage of transverse electromagnetic propagation properties to develop a specialized TEM integral equation. An expression for the characteristic impedance is developed using the MoM results. The characteristic impedance is calculated for various degrees of center conductor miss alignment.

This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work.

This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work.

As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.
