Insulator Charging in RF MEMS Capacitive Switches (Paperback) (ISBN-13: 9781288311644)

While capacitive radio frequency microelectromechanical (RF MEM) switches are poised to provide a low cost, low power alternative to current RF switch technologies, there are still reliability issues limiting switch lifetime. Previous research identified insulator charging as a primary cause of switch failure. Changes in switch pull-in and release voltages were measured to provide insight into the mechanisms responsible for charging and switch failure. A spatial and temporal dependent model was developed to describe silicon nitride's time-dependent charging as a function of applied bias. This model was verified by applying constant biases to metal-silicon nitride-silicon capacitors and tracking flatband voltage shifts. This knowledge of silicon nitride was then applied to MEM switches. Using novel waveforms and exploiting differences in actuation characteristics allowed the determination of charging characteristics and the investigation of switch failure. Results show tunneling is responsible for changes in the pull-in voltages - this includes a super-saturation effect explained by a steady-state trap charge and discharge condition. A program that models switch actuation was enhanced to include the time-dependent tunneling model. Finally, it was discovered insulator charging cannot explain permanent switch failure; instead, stiction from a contaminant on the insulator surface is likely the cause.

This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work.

This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work.

As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.
