Laser Security System (Paperback) (ISBN-13: 9781728981758)

LASER-Ray goes through long distance without scattering effect and the Ray is almost invisible. Only the radiation point and incident point is visible. So by this security project we can make an invisible boundary of a sensitive area. There is two part of the system. One is transmitter and other is receiver. The transmitter part is built with a LASER radiator, a pair of dry cell batteries, an on-off switch and a stand to hold it. The receiver side, there is a focusing LDR (Light depending Resistor) sensor to sense the LASER continuously. The LDR sensor also holds with a stand and it connected with the main driver circuit. The circuit has two parts. One is filtered the signal of discontinuity ray and others is alarm circuit. When anybody crossover the invisible ray the main circuit sense the discontinuity by sensor and turn on the alarm circuit. If once the alarm circuit is on it will still ringing until push the reset button. There is two option of ringing. One is the duration of ringing depends on preset timer and another reset manually. Any option can be set by DPDT switch. If anybody wants to bind a sensitive area with the single ray he has to use mirror at every corner to reflect it. The system has built with low cost and high performance. The power consumption of the system is very low.

Author: Richa Chauhan,Rakesh Sharma,Akshay Meena
ISBN-10: 1728981751
ISBN-13: 9781728981758
Publisher: Independently Published
Language: English
Published: 10/21/2018
Pages: 26
Format: Paperback
Weight: 0.12lbs
Size: 9.00h x 6.00w x 0.06d
