Measurement methodology for coordinate measuring machines - CMM (Paperback) (ISBN-13: 9786207883677)

Measuring shape errors on coordinate measuring machines is a process that is widely used nowadays due to the ease and speed with which the results of a given characteristic can be obtained. The aim of this work was to establish a rule for determining the minimum number of points to be touched when measuring the roundness of various parts. For the case study, measurements were taken on a part manufactured exclusively for this work, where the initial objective was achieved through calculations and comparisons. Based on the results of the measurements, a rule was defined which consists of touching 1 point/mm of the calculated perimeter, considering the nominal diameter specified in the drawing. The use of the rule allows for greater confidence in the results obtained, as it establishes a standard for circularity measurements in various diameters and a reduction in measurement costs, as the time spent on this process is considerably reduced (72.9% in the case studied) depending on the number of points chosen by the metrologist.

Author: Wanderson Stoco, Andr? de Lima, Hamilton Torrezan
ISBN-10: 6207883675
ISBN-13: 9786207883677
Publisher: Our Knowledge Publishing
Language: English
Published: 07/27/2024
Pages: 64
Format: Paperback
Weight: 0.23lbs
Size: 9.00h x 6.00w x 0.15d
