On the Face Stability of Shallow Tunnels in Sand (Paperback) (ISBN-13: 9783832521493)

Various models have been proposed for the prediction of the necessary support pressure at the face of a shallow tunnel. To assess their quality, the collapse of a tunnel face was modelled with small scale model tests at single gravity. The evolution of the failure mechanism and the development of the support force at the face in dry sand were investigated. The observed displacement patterns show a negligible influence of overburden on the extent and evolution of the failure zone. The latter is significantly influenced, though, by the initial density of the sand: in dense sand a chimney-wedge-type collapse mechanism developed, which propagated towards the soil surface. Initially loose sand did not show any development of a discrete collapse mechanism. The necessary support force was neither influenced by the overburden nor the initial density. A comparison with quantitative predictions by several theoretical models showed that the measured necessary support pressure is overestimated by most of the models. Only those by Vermeer/Ruse and Leca/Dormieux were able to predict the necessary support pressure on a 95 % confidence level. A three-dimensional finite element investigation of face stability served to assess the ability of two constitutive models, an elastoplastic Mohr-Coulomb and a hypoplastic model, to predict the necessary support pressure and the displacements at the tunnel face. The simulation of the small scale experiments revealed that the observed necessary support pressure and incremental displacements were predicted sufficiently well with both constitutive models.

Author: Ansgar Kirsch
ISBN-10: 3832521496
ISBN-13: 9783832521493
Publisher: Logos Verlag Berlin
Language: English
Published: 02/15/2009
Pages: 212
Format: Paperback
