Optimal Process Design of 2- and 3-Phase Horizontal Production Separators for Oil and Gas Installations: A Mathematical Programming Formulation in Exc (Paperback) (ISBN-13: 9781694977212)

This book details a Microsoft Excel spreadsheet which models numerically the following key design factors for horizontal separators and optimizes the vessel dimensions using the Solver add-in, allowing the engineer to minimize the size of the vessel and associated piping whilst achieving satisfactory performance in the separation, process control and safeguarding functions: -Gravity settling zone dimensions for successful phase separation. -Provision of adequate liquid hold up times and height differences between contiguous level control and trip settings.-Type of inlet device, and its impact upon the size of inlet pipework and the dimensions of the separator vessel.-Nozzle sizing according to erosional, velocity head and velocity criteria, and the impact on vessel dimensions.-Maintaining axial velocities of oil and water phases within acceptable limits.-Prevention of re-entrainment of oil droplets into the gas phase.-Prevention of transient gas blowby or gross carryover of liquid during unplanned shutdown.-Provision of adequate liquid and gas holdup volumes for slugging and surging.-Prevention of spurious trips due to foaming, where applicable.The principal calculation method for dimensioning the gravity settling zone of the vessel is based on settling theory, according to which droplets / bubbles of certain diameters settle to their respective continuous phases, however the spreadsheet allows the engineer to concurrently specify minimum allowable oil and / or water retention times if desired.

Author: John T. Small
ISBN-10: 1694977218
ISBN-13: 9781694977212
Publisher: Independently Published
Language: English
Published: 09/22/2019
Pages: 80
Format: Paperback
Weight: 0.61lbs
Size: 11.00h x 8.50w x 0.21d
