Optimization of a Multilayer Photothermal Sensor for Infrared Spectroscopy (Paperback) (ISBN-13: 9781249594239)

Mathematical modeling and atomic force microscopy were used to optimize a multi-layer reed sensor for use in a new infrared detection system. The reed sensor is designed to deflect in response to temperature variations. In this system, a sample absorbs infrared light (modulated at some frequency to reduce noise) and releases heat into the reed. The layers expand differently, causing the reed to deflect. The deflection is influenced by geometric parameters, such as length and thickness of each layer, and also by the frequency of modulation. Deflection is easily measured using an atomic force microscope. This research applied a mathematical model to the reed sensor, explored the effect of varying geometric parameters, and used experimental testing to evaluate the model. Several reeds were tested to validate the model, which predicted sensitivity, maximum deflection, resonance frequency, and signal to noise ratio. Varying concentrations of absorbing chemical were deposited in the reed, to cause a change in deflection. A cantilever reed having three layers was modeled mathematically using a recently developed thermal model and a mechanical model based on two-layer theory.

Author: Janine J. Wiggins
ISBN-10: 1249594235
ISBN-13: 9781249594239
Publisher: Biblioscholar
Language: English
Published: 10/09/2012
Pages: 68
Format: Paperback
Weight: 0.24lbs
Size: 9.21h x 6.14w x 0.14d
