Optimization of Blended Wing Body Composite Panels Using Both Nastran and Genetic Algorithm (Paperback) (ISBN-13: 9781289147358)

The blended wing body (BWB) is a concept that has been investigated for improving the performance of transport aircraft. A trade study was conducted by evaluating four regions from a BWB design characterized by three fuselage bays and a 400,000 lb. gross take-off weight (GTW). This report describes the structural optimization of these regions via computational analysis and compares them to the baseline designs of the same construction. The identified regions were simplified for use in the optimization. The regions were represented by flat panels having appropriate classical boundary conditions and uniform force resultants along the panel edges. Panel-edge tractions and internal pressure values applied during the study were those determined by nonlinear NASTRAN analyses. Only one load case was considered in the optimization analysis for each panel region. Optimization was accomplished using both NASTRAN solution 200 and Genetic Algorithm (GA), with constraints imposed on stress, buckling, and minimum thicknesses. The NASTRAN optimization analyses often resulted in infeasible solutions due to violation of the constraints, whereas the GA enforced satisfaction of the constraints and, therefore, always ensured a feasible solution. However, both optimization methods encountered difficulties when the number of design variables was increased. In general, the optimized panels weighed less than the comparable baseline panels.

Author: Nasa Technical Reports Server (Ntrs),Andrew E. Lovejoy
ISBN-10: 1289147353
ISBN-13: 9781289147358
Publisher: Bibliogov
Language: English
Published: 06/28/2013
Pages: 76
Format: Paperback
Weight: 0.34lbs
Size: 9.69h x 7.44w x 0.16d
