Preliminary Low-Speed Wind-Tunnel Investigation of Some Aspects of the Aerodynamic Problems Associated with Missiles Carried Externally in Positions N (Paperback) (ISBN-13: 9781289264055)

A low-speed wind-tunnel investigation has been made of some aspects of the aerodynamic problems associated with the use of air-to-air missiles when carried externally on aircraft. Measurements of the forces and moments on a missile model for a range of positions under the mid-semispan location of a 45deg sweptback wing indicated longitudinal and lateral forces with regard to both carriage and release of the missiles. Surveys of the characteristics of the flow field in the region likely to be traversed by the missiles showed abrupt gradients in both flow angularity and in local dynamic pressure. Through the use of aerodynamic data on the isolated missile and the measured flow-field characteristics, the longitudinal forces and moments acting on the missile while in the presence of the wing-fuselage combination could be estimated with fair accuracy. Although the lateral forces and moments predicted were qualitatively correct, there existed some large discrepancies in absolute magnitude.

Author: U S Government Printing Office
ISBN-10: 1289264058
ISBN-13: 9781289264055
Publisher: Bibliogov
Language: English
Published: 07/31/2013
Pages: 36
Format: Paperback
Weight: 0.18lbs
Size: 9.69h x 7.44w x 0.07d
