Siemens NX 12 Design Fundamentals: A Step by Step Guide (Paperback) (ISBN-13: 9781723326097)

This textbook explains how to create solid models, assemblies and drawings using Siemens NX 12. NX is a three dimensional CAD/CAM/CAE software developed by Siemens PLM Software Inc., Germany. This textbook is based on NX 12. Users of earlier releases can use this book with minor modifications. We provide files for exercises via our website. Almost all files are in NX 6.0 so readers can open the files using NX 6.0 and later releases.It is assumed that readers of this textbook have no prior experience in using Siemens NX for modeling 3D parts. This textbook is suitable for anyone interested in learning 3D modeling using Siemens NX.Each chapter deals with the major functions of creating 3D features using simple examples and step by step, self-paced exercises. Additional drawings of 3D parts are provided at the end of each chapter for further self exercises. The final exercises are expected to be completed by readers who have fully understood the content and completed the exercises in each chapter.Topics covered in this textbook- Chapter 1: Basic components of Siemens NX 12, options and mouse operations.- Chapter 2: Basic step by step modeling process of NX 12.- Chapter 3 and 4: Creating sketches and sketch based features.- Chapter 5: Usage of datums to create complex 3D geometry.- Chapter 6: Additional modeling commands such as fillet, chamfer, draft and shell.- Chapter 7: Modification of 3D parts to take advantage of parametric modeling concepts.- Chapter 8: Copying features, modeling objects and bodies.- Chapter 9: Additional modeling commands such as trim body, tube, sweep along guide, emboss and various commands in synchronous modeling.- Chapter 10: Advanced sketch commands.- Chapter 11: Measuring and verifying 3D geometries.- Chapter 12 and 13: Constructing assembly structures and creating or modifying 3D parts in the context of assembly.- Chapter 14 and 15: Creating drawings for parts or assemblies.- Appendix A: Selecting Objects

Author: Jaecheol Koh
ISBN-10: 1723326097
ISBN-13: 9781723326097
Publisher: Createspace Independent Publishing Platform
Language: English
Published: 07/18/2018
Pages: 662
Format: Paperback
Weight: 2.56lbs
Size: 9.69h x 7.44w x 1.33d
