Sri Yantra step by step draw in AutoCAD (Paperback) (ISBN-13: 9789395766623)

A Sri Yantra designed with accuracy and precision is precious, beautiful and highly benevolent. To begin drawing, use a 2D drafting engineering software e.g. AutoCAD, BricsCAD, nanoCAD, LibreCAD etc.

• Set the Dimensions precision to four decimal places, e.g., 0.0000
• With each Line, Angle, or Circle drawn, take the Dimension and see if it matches exactly.
• Even a slight error shall make the Sri Yantra lose its Beauty and Preciousness.
• 1 Square ABCD, side 200.
• 2 Bisect Square at J,
  • make right angle Triangle JCD with hypotenuse JC = 223.6068, Angle CJD = 63.4349
• 3 Draw Black Circle with center at J, radius = hypotenuse JC = 223.6068
• 4 Extend Square ABCD to a Rectangle ABEF, where longer side AF = BE = 323.6068
• 5 Draw Green Circle with center at A, radius = 323.6068
• 6 Extend side of Square DC to touch Green Circle at upper point g. The length Dg = 254.4039
  • For exactness,
  • Extend side of Square CD to touch Green Circle at lower point. This length = 254.4039
  • These both lengths must be Equal. This is just to check if we are going right so far.
  • If both these lengths are Equal, we have found the Apex g for our Triangle T1u.
• 7 Now join A to g, and we get the Side Ag of our Golden Ratio Triangle T1u.
  • Note that Side Ag = radius of Green Circle = 323.6068
• 8 Copy and Mirror the Side Ag to get the Side gi of Golden Ratio Triangle Triangle.
• 9 Join points A to i to get Base Ai of Golden Ratio Triangle T1u

Golden Ratio Triangle T1u Largest Upwards Apex Triangle is starting Point for Sri Yantra.

• Dimensions for Golden Ratio Triangle T1u = Agi must be precisely
  • Baseline length = 400
  • Isosceles Side Length each = 323.6068
  • Isosceles Angle each = 51.82729

Author: Ashwini Kumar Aggarwal
ISBN-10: 939576662X
ISBN-13: 9789395766623
Publisher: Devotees of Sri Sri Ravi Shankar Ashram
Language: English
Published: 06/30/2023
Pages: 126
Format: Paperback
Weight: 0.93lbs
Size: 11.00h x 8.50w x 0.33d
