SRS Computer Animation and Drive Train System (Paperback) (ISBN-13: 9781288911134)

The spinning rocket simulator (SRS) is an ongoing project at Oral Roberts University. The goal of the SRS is to gather crucial data concerning a spinning rocket under thrust for the purpose of analysis and correction of the coning motion experienced by this type of spacecraft maneuver. The computer animation simulates a virtual, scale model of the component of the SRS that represents the spacecraft itself. This component is known as the (VSM), or virtual spacecraft model. During actual physical simulation, this component of the SRS will experience a coning. The goal of the animation is to cone the VSM within that range to accurately represent the motion of the actual simulator. The drive system of the SRS is the apparatus that turns the actual simulator. It consists of a drive motor, motor mount and chain to power the simulator into motion. The motor mount is adjustable and rigid for high torque application. A digital stepper motor controller actuates the main drive motor for linear acceleration. The chain transfers power from the motor to the simulator via sprockets on both ends.

Author: National Aeronautics and Space Administr,Daniel Arthun,Christian Schachner
ISBN-10: 1288911130
ISBN-13: 9781288911134
Publisher: Biblioscholar
Language: English
Published: 03/12/2013
Pages: 38
Format: Paperback
Weight: 0.19lbs
Size: 9.69h x 7.44w x 0.08d
