The Concept Design of a Split Flow Liquid Hydrogen Turbopump (Hardcover) (ISBN-13: 9781025072791)

An initial design of a split flow liquid hydrogen turbopump for the Dual Expander Aerospike Nozzle (DEAN) upper stage engine was completed. The engine nozzle is an annular aerospike. The engine cycle requires a combustion chamber pressure of 1,740 psia. The DEAN is designed to deliver 57,200 lbf of thrust and 472 seconds of Isp. The turbopump design was completed using a meanline software tool. The design consists of a single piece rotor, with a two-stage pump and radial inflow turbine. The turbopump flow rates are 15.1 and 7.55 lbm/s into the first and second stage, respectively. The first and second stage pumps use unshrouded impellers. An interstage transfer models the fluid split flow. The fluid for each stage exits through a volute. The first and second stage impeller hub-tip ratios are 0.3 and 0.35, respectively. The turbine is a full admission reaction type. At the design condition, the turbine delivers 3,607 horsepower at a total pressure ratio of 1.84.

This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work.

This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work.

As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.
