Utilizing NX Advanced Simulation for NASA's New Mobile Launcher for Ares-l (Paperback) (ISBN-13: 9781289247973)

This slide presentation reviews the use of NX to simulate the new Mobile Launcher (ML) for the Ares-I. It includes: a comparison of the sizes of the Saturn 5, the Space Shuttle, the Ares I, and the Ares V, with the height, and payload capability; the loads control plan; drawings of the base framing, the underside of the ML, beam arrangement, and the finished base and the origin of the 3D CAD data. It also reviews the modeling approach, meshing. the assembly Finite Element Modeling, the model summary. and beam improvements.

Author: Nasa Technical Reports Server (Ntrs),Christopher Brown
ISBN-10: 1289247978
ISBN-13: 9781289247973
Publisher: Bibliogov
Language: English
Published: 07/29/2013
Pages: 34
Format: Paperback
Weight: 0.18lbs
Size: 9.69h x 7.44w x 0.07d
